Features

  • Accurate & User Friendly
  • Self Priming
  • Rugged PWM based DC motor Drive
  • Switches for ON/OFF,Auto/Manual,Direction reversal functions
  • Occlusion adjustable Spring loaded Pump Head
  • Complied with CE requirement
No.of Channelsone
Flow Rate20 ml to 2500 ml/min
Speed10 to 196 RPM
Tubing3 to 10 mm ID, 1.5 to 2 mm Wall thickness
No.of Rollers2
PressureUP to 2 Bar
Accuracy+/- 2%
Input Supply230V +/- 10%, 50Hz, Single phase AC, 60 Watt
DisplayThree digit LED Seven Segment Display
MotorDC Geared Motor (Cont. Duty)
DrivePWM Based DC Motor Drive
Mode Of OperationAuto / Manual
Manual ModeSpeed Variation by means of a multi turn Potentiometer
Auto ModeSpeed Variation by means of External 4...20 mA Signal
Weight8.5 Kgs (Approx.)
EnclosurePowder coated Aluminium
Outer ARMAnodized Aluminium
ARM CoverTransparent Polycarbonate
RotorS.S.316 / S.S.304
RollersCarbon Filled Nylon
